PRODUCT CODE: F-PCSR-A01-V t and G
Mono Pitch Ramsbottom Door Canopy/Bay roof/porch. Low maintenance.

Product Code - F-PCSR-A01

The Ramsbottom Door Canopy is a high quality softwood joinery frame built to our standard projection. Standard width 1650mm (Any width can be manufactured to your special requirements up to a maximum of four metres long, please contact us for a quote).

Depending on choice of cladding, if not stocked, please allow 14 working days for delivery. We will advise on ordering.

The door canopy in UPVC or Tricoya Clad will be classed as a low maintenance door canopy.

Available to be mounted on posts as a porch type. Please contact us for a qoute. These are regularly used as a traditional Bay roof/canopy. Bare units for cladding on site can be manufactured.

If looking for a bay please complete the enclosed measurements confirmation form for a qoute.

F-PCSR-A01- UPVC

Choose between Black or White (grained UPVC) soffit/cheeks. Please state the colour in the notes section before ordering.

F-PCSR-A01- Tricoya

Also available with Tricoya which is profiled V T & G, option without this profile also (low maintenance but will require painting on site).

F-PCSR-A01- Traditional V T & G matchboard
We can manufacture this with traditional V T &G matchboard. This will require regular checks for maintenance of the paint finish.

Please note the image shown is a fully finished site photo, Black grained UPVC version, supported on our F-CB685 brackets

Fixing kit-MP1

X6 M10 X 130mm Thunder Bolts & washers

X6 25mm Oak mushroom Caps

X4 100mm Concrete screws

x2 70mm x 6mm wood screws

•  The canopy can receive tiles; slate or felt tiles. Comes with two F-GS2 brackets. Different styled brackets can be ordered, please contact us.
• In the case of covering a bay this canopy/roof can be insulated on site.
• Technical- Please see product spec for the drawing.750mm projection, 710mm height above door head, weight 28kg.
• Prices excludes delivery.
• Fixing kit details see fixings section MP1

All our Timber products are FSC and are now treated with a clear wood preservative as defined in BS/EN 335-1:1994. This product protects the wood surface against wood destroying and wood discolouring funghi and satisfies the performance requirements of EN599-1.
